Buick Enclave I (2007-2013) rear console accessory power outlet Wiring diagram
This page shows the only wiring diagram for the component.rear console accessory power outlet, which is found in the car Buick Enclave I (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear console accessory power outlet (1 of 1)
BLK WIRE
BODY HEAD CONTROL UP MODULE DISPLAY (BCM) (HUD) (IF EQUIPPED)
BUICK: W/ HID PROJECTOR LOW BEAM, HALOGEN PROJECTOR HIGH BEAM
CENTER CONSOLE ACCESSORY POWER OUTLET
CHEVROLET EXCEPT CHEVROLET
DAYTIME RUNNING LAMP RELAY
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DR/LCK FUSE
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER DOOR UNLATCH RELAY
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
DRL 2 FUSE (HID PROJECTOR LOW BEAM, HALOGEN PROJECTOR HIGH BEAM, GMC)
EXCEPT BUICK: W/ HID PROJECTOR BEAM, HALOGEN PROJECTOR HIGH BEAM
FROM AUX POWER FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 5)
FROM BATT 3 FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 5)
FROM CIGAR LIGHTER FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 5)
FROM HTD/ SEAT FUSE (DIAGRAM 2 OF 5) HVAC FUSE
FROM RR APO FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 2 OF 5)
HVAC CONTROL MODULE
I/P ACCESSORY POWER OUTLET
LEFT DAYTIME RUNNING LAMP,
LEFT REAR WINDOW SWITCH
PASSENGER DOOR LOCK/WINDOW SWITCH
POWER OUTLET
PWR WNDW CIRCUIT BREAKER
REAR ACCESSORY
REAR CONSOLE ACCESSORY POWER OUTLET
REAR WINDOW WASHER PUMP RELAY
REAR WINDOW WIPER MOTOR
REAR WPR FUSE
RED WIRE
RIGHT REAR WINDOW PASSENGER SWITCH WINDOW SWITCH
W/ DRL DRL FUSE
W/ EXPRESS POWER WINDOWS
W/ FLOOR COMPARTMENT
W/O EXPRESS POWER WINDOWS
W/O FLOOR COMPARTMENT
WHT WIRE
WINDSHIELD WASHER PUMP RELAY
Go to component -> Power distribution circuit (4 of 5) -> REAR CONSOLE ACCESSORY POWER OUTLET
