Buick Enclave I (2007-2013) i/p accessory power outlet Wiring diagrams
This page contains all the electrical diagrams for the component. i/p accessory power outlet, in which he is found in the car Buick Enclave I (2007-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram i/p accessory power outlet (1 of 2)
8-WAY POWER SEAT ADJUSTER
AUTOMATIC TRANSMISSION
AUXILIARY BLOWER MOTOR CONTROL MODULE
BATT 2 FUSE
BCK/UP/STOP FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
CIGAR LIGHTER FUSE
CONTROL SOLENOID VALVE ASSEMBLY
DRIVER DRIVER SEAT SEAT LUMBAR ADJUSTER SWITCH SWITCH
FROM TRLR PWR FUSE
I/P ACCESSORY POWER OUTLET
I/P FUSE BLOCK (BEHIND
L/GATE RELAY (W/ MANUAL LIFTGATE)
LIFTGATE MODULE (LGM)
LT/PWR/ SEAT CIRCUIT BREAKER
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH (IF EQUIPPED)
PASSENGER DOOR LOCK/ WINDOW SWITCH
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SWITCH
PDM FUSE
PWR COLUMN CIRCUIT BREAKER
PWR L/GATE FUSE
PWR OUTLET FUSE
PWR/ MIR FUSE
REAR FOG LAMP RELAY
RED WIRE
RIGHT END OF DASH)
RR APO FUSE
RR FOG FUSE
RR HVAC FUSE
RT/PWR/ SEAT CIRCUIT BREAKER LT/TRN/SIG FUSE
RT/TRN/SIG FUSE
RVC SNSR FUSE
S/ROOF/ SUNSHADE FUSE
STEERING WHEEL/COLUMN TILT/TELESCOPE SWITCH (IF EQUIPPED)
STOP LAMP FUSE
STOP LAMP RELAY (IF EQUIPPED)
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
TCM FUSE
TO ACCESSORY AC/DC POWER CONTROL MODULE (DIAGRAM 5 OF 5)
TO FOG LAMP FUSE (DIAGRAM 3 OF 5)
TO HVAC FUSE (DIAGRAM HTD/COOL SEAT FUSE 4 OF 5)
TO REAR ACCESSORY POWER OUTLET (DIAGRAM 4 OF 5)
TRAILER PROVISION (BLUNT CUT)
TRLR BRK FUSE
W/ 8-WAY POWER SEAT ADJUSTER, W/O MEMORY
W/ EXPRESS POWER WINDOWS
W/ MEMORY 8-WAY POWER SEAT ADJUSTER
W/ MEMORY, FRONT COOLING SEAT HEATER
W/ MULTI-DIRECTIONAL DRIVER SEAT ADJUSTER
W/ POWER LIFTGATE
W/ POWER SLIDING SUNROOF
W/ POWER TILT, TELESCOPING
W/ TRAILER PROVISIONS
W/O MEMORY
WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> I/P ACCESSORY POWER OUTLET
Wiring diagram i/p accessory power outlet (2 of 2)
BLK WIRE
BODY HEAD CONTROL UP MODULE DISPLAY (BCM) (HUD) (IF EQUIPPED)
BUICK: W/ HID PROJECTOR LOW BEAM, HALOGEN PROJECTOR HIGH BEAM
CENTER CONSOLE ACCESSORY POWER OUTLET
CHEVROLET EXCEPT CHEVROLET
DAYTIME RUNNING LAMP RELAY
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DR/LCK FUSE
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER DOOR UNLATCH RELAY
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
DRL 2 FUSE (HID PROJECTOR LOW BEAM, HALOGEN PROJECTOR HIGH BEAM, GMC)
EXCEPT BUICK: W/ HID PROJECTOR BEAM, HALOGEN PROJECTOR HIGH BEAM
FROM AUX POWER FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 5)
FROM BATT 3 FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 5)
FROM CIGAR LIGHTER FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 5)
FROM HTD/ SEAT FUSE (DIAGRAM 2 OF 5) HVAC FUSE
FROM RR APO FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 2 OF 5)
HVAC CONTROL MODULE
I/P ACCESSORY POWER OUTLET
LEFT DAYTIME RUNNING LAMP,
LEFT REAR WINDOW SWITCH
PASSENGER DOOR LOCK/WINDOW SWITCH
POWER OUTLET
PWR WNDW CIRCUIT BREAKER
REAR ACCESSORY
REAR CONSOLE ACCESSORY POWER OUTLET
REAR WINDOW WASHER PUMP RELAY
REAR WINDOW WIPER MOTOR
REAR WPR FUSE
RED WIRE
RIGHT REAR WINDOW PASSENGER SWITCH WINDOW SWITCH
W/ DRL DRL FUSE
W/ EXPRESS POWER WINDOWS
W/ FLOOR COMPARTMENT
W/O EXPRESS POWER WINDOWS
W/O FLOOR COMPARTMENT
WHT WIRE
WINDSHIELD WASHER PUMP RELAY
Go to component -> Power distribution circuit (4 of 5) -> I/P ACCESSORY POWER OUTLET
