Buick Enclave I (2007-2013) driver heated, cooled seat switch Wiring diagram
This page shows the only wiring diagram for the component.driver heated, cooled seat switch, which is found in the car Buick Enclave I (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver heated, cooled seat switch (1 of 1)
4 5 B+
BACK
BACK CUSHION LED
BACK CUSHION SIG
BACK IND
BACK LED
BACK SIG
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CUSHION, BACK
CUSHION, BACK IND
DK BLU WIRE
DK GRN WIRE
DRIVER HEATED, COOLED SEAT SWITCH
GRY WIRE
HI TEMP IND
HI TEMP IND CTRL
HIGH TEMP IND CTRL
LO SPD GMLAN SERIAL DATA
LOGIC DRIVER DOOR LOCK/ WINDOW SWITCH
LOGIC PASSENGER DOOR LOCK/ WINDOW SWITCH
LOW REF
LOW TEMP IND
LOW TEMP IND CTRL
LT BLU WIRE
MED IND
MED IND CTRL
PASSENGER HEATED, COOLED SEAT SWITCH
PPL
PPL/WHT WIRE
RED/WHT WIRE
TAN WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Climate control seats circuit (2 of 2) -> DRIVER HEATED, COOLED SEAT SWITCH
