Buick Enclave I (2007-2013) dr lock actr unlock crtl dr lock actr lock crtl Wiring diagrams
This page contains all the electrical diagrams for the component. dr lock actr unlock crtl dr lock actr lock crtl, in which he is found in the car Buick Enclave I (2007-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dr lock actr unlock crtl dr lock actr lock crtl (1 of 2)
AIR BAG FUSE
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DR LOCK ACTR UNLOCK CRTL DR LOCK ACTR LOCK CRTL
DRIVER INFORMATION CENTER (DIC) DISPLAY
DSPLY FUSE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
IGN VOLT
INSTRUMENT PANEL CLUSTER (IPC)
LEFT REAR DOOR LATCH (REAR OF LEFT REAR DOOR)
LIFTGATE LATCH ASSEMBLY (W/O POWER LIFTGATE) (BOTTOM CENTER OF LIFTGATE)
LOCK
LOGIC
LOW REF
LT BLU/BLK WIRE
LT GRN/BLK WIRE
PASSENGER DOOR LATCH ASSEMBLY (REAR OF FRONT PASSENGER'S DOOR)
PASSENGER DOOR LOCK/WINDOW SWITCH
PDM FUSE
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (IF EQUIPPED)
RF DOOR AJAR
SECURITY IND
SER DATA
SERIAL DATA
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
UNLOCK
YEL WIRE
Go to component -> Forced entry circuit (2 of 2) -> DR LOCK ACTR UNLOCK CRTL DR LOCK ACTR LOCK CRTL
