Buick Enclave I (2007-2013) 26 14 ser data bus+ ser data bus- Wiring diagram
This page shows the only wiring diagram for the component.26 14 ser data bus+ ser data bus-, which is found in the car Buick Enclave I (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 26 14 ser data bus+ ser data bus- (1 of 1)
26 14 SER DATA BUS+ SER DATA BUS-
5 28 VAR HIGH EFFORT VAR LOW EFFORT
ABS MTR FUSE
AIR BAG FUSE
ANTI-LOCK BRAKES SYSTEM
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF ENGINE COMPT)
GROUND LOW REF 12-VOLT REF B+
HOT AT ALL TIMES
HOT W/ IGN RELAY ENERGIZED
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LT BLU WIRE
LT GRN/BLK WIRE
PNK IGN GMLAN WIRE
PNK WIRE
RED/BLK WIRE
SERIAL DATA
STEERING WHEEL SPEED POSITION SENSOR (TOP OF STEERING COLUMN)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
VARIABLE EFFORT STEERING ACTUATOR (ON STEERING GEAR)
WHT WIRE
Go to component -> Electronic power steering circuit -> 26 14 SER DATA BUS+ SER DATA BUS-
