Buick Enclave I (2007-2013) 14 15 rr door ajar lr door ajar Wiring diagram

1 2 3 4 IGN VOLT GND LIN NETWORK 14 15 RR DOOR AJAR LR DOOR AJAR 16 17 SER DATA BUS+ SER DATA BUS- 2500 2501 COMPUTER DATA LINES SYSTEM AIR CONDITIONING/ HEATER SYSTEM BLK WIRE BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH) BUS - COMPUTER DATA LINES SYSTEM DK GRN WIRE DOWN WINDOWS) DR/LCK FUSE DRIVER DOOR LATCH (W/ EXPRESS UP/ DRIVER DOOR LATCH (W/O EXPRESS UP/ DOWN WINDOWS) DRIVER DOOR LOCK/ WINDOW SWITCH (W/ EXPRESS UP/ DOWN WINDOWS) ELECTRONIC COMPASS MODULE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) LEFT REAR DOOR LATCH (REAR OF LEFT REAR DOOR) LF DOOR AJAR LIFTGATE AJAR 10 8 LF DOOR AJAR RF DOOR AJAR LIFTGATE LATCH ASSEMBLY (W/ MANUAL LIFTGATE) (BOTTOM CENTER OF LIFTGATE) LIN NETWORK BUS LOGIC LOW REF LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PARK BRAKE SWITCH (ON PARK BRAKE ASSEMBLY) PASSENGER DOOR LATCH (W/ EXPRESS UP/ DOWN WINDOWS) PASSENGER DOOR LATCH (W/O EXPRESS UP/ DOWN WINDOWS) PASSENGER DOOR LOCK/ WINDOW SWITCH (W/ EXPRESS UP/ DOWN WINDOWS) PDM FUSE PNK WIRE PNK/ (NEAR BASE OF LEFT "D" PILLAR) WIRE PNK/BLK WIRE POWER MODE PRK BRK SW SIG RED/WHT WIRE RF DOOR AJAR RIGHT REAR DOOR LATCH (REAR RIGHT REAR DOOR) SERIAL DATA TAN WIRE TAN/BLK WIRE TAN/WHT WIRE YEL WIRE
