Buick Enclave I (2007-2013) 1 55 42 ground gmlan ser data bus- gmlan ser data bus+ Wiring diagram

1 55 42 GROUND GMLAN SER DATA BUS- GMLAN SER DATA BUS+ 22 8 9 CRUISE CNTRL IND GMLAN SER DATA BUS+ GMLAN SER DATA BUS- 52 56 49 15 34 48 25 47 STOP LAMP SUP VOLT B+ ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL) AIR BAG FUSE APP SEN SIG 1 LOW REF APP SEN SIG 2 LOW REF PPL AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY CRUISE CNTRL SW SIG CRUISE IND CRUISE SWITCH DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ECM FUSE END OF DASH) ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE) GMLAN SERIAL DATA GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED I/P FUSE BLOCK (BEHIND RIGHT IGN INSTRUMENT PANEL CLUSTER (IPC) LEFT STEERING WHEEL CONTROL SWITCH LOGIC LOW REF STOP LAMP SW SIG LT BLU WIRE LT GRN WIRE OUTPUT SHAFT SPEED (OSS) SENSOR PNK WIRE PPL PPL 12-VOLT REFERENCE RED/WHT WIRE RESET+ SET- SOUND SYSTEMS STOP LAMP SUP VOLT TAN WIRE TAN/BLK WIRE THROTTLE BODY (TOP REAR OF ENGINE) TP SEN SIG 1 LOW REF TD SENS SIG 2 TAC MOTOR CTRL 2 TAC MOTOR CTRL 1 TRANSMISSION CONTROL MODULE TRANSMISSIONS, SOUND SYSTEMS UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL) WHT WIRE WHT/BLK WIRE YEL WIRE
