Buick Enclave I (2007-2013) 1 1 1 center speaker low sbfr speaker low drain wire pnk Wiring diagram
This page shows the only wiring diagram for the component.1 1 1 center speaker low sbfr speaker low drain wire pnk, which is found in the car Buick Enclave I (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 1 1 center speaker low sbfr speaker low drain wire pnk (1 of 1)
1 1 1 CENTER SPEAKER LOW SBFR SPEAKER LOW DRAIN WIRE PNK
5 6 12 DRAIN WIRE AUDIO SIG LOW REF PNK
6972 6973 NAVIGATION SYSTEM
8 1 2 DRAIN WIRE AUDIO SIG PLAYBACK DEVICE
AUXILIARY AUDIO JACK (W/ USB)
AUXILIARY AUDIO JACK NAVIGATION ANTENNA RADIO ANTENNA
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COAX
COMPUTER DATA LINES SYSTEM
DISC (DVD) DISPLAY
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF ENGINE COMPT)
ENABLE SIG
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
LEFT FRONT SPEAKER
LEFT FRONT TWEETER SPEAKER
LOW SERIAL DATA
LR SPEAKER LOW RR SPEAKER LOW AUDIO COMMON SIG
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NAVIGATION ANTENNA (BEHIND RIGHT SIDE OF DASH)
NCA WIRE
ON RADIO
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RADIO
RADIO ANTENNA
RDO FUSE
RED/WHT WIRE
SATELLITE RADIO CIRCUIT
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
USB CABLE COAX
USB CABLE USB
VEH SIG
VIDEO SYSTEM CIRCUIT
W/ RSE
W/ SURROUND AMPLIFIER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, premium (1 of 3) -> 1 1 1 CENTER SPEAKER LOW SBFR SPEAKER LOW DRAIN WIRE PNK
