Buick Century VI (1997-2005) stop lamp sw out Wiring diagram
This page shows the only wiring diagram for the component.stop lamp sw out, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp sw out (1 of 1)
1442 1442 251 251 BATTERY BATTERY GROUND GROUND
ABS FUSE
ABS FUSE 1
ANTI-LOCK FAIL IND
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRAKE IND
BRAKE PRESSURE MODULATOR VALVE
BRN WIRE
BRN/WHT WIRE
CLUSTER FUSE
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
DELIVERED TORQUE
DESIRED TORQUE
DK GRN WIRE
ELECTRONIC POWER STEERING SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
INSTRUMENT PANEL CLUSTER
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LOW TRAC IND
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK PNK WIRE
PNK WIRE
PPL
PUMP MOTOR
RED WIRE
REGAL
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
SERIAL DATA SIGNAL
SPLICE PACK
STOP LAMP SW OUT
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
STOP LAMPS FUSE
STRNG VAR ASSIST MOTOR STRNG VAR ASSIST MOTOR
TAN WIRE
TAN/BLK WIRE
TRAC OFF IND
TRACTION CONTROL SWITCH
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER)
VENT TUBE
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit -> STOP LAMP SW OUT
