Buick Century VI (1997-2005) set sw Wiring diagram
This page shows the only wiring diagram for the component.set sw, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram set sw (1 of 1)
72 64 DISABLE OUTPUT VSS HIGH
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BRN WIRE
CRUISE CONTROL MODULE
CRUISE CONTROL RELEASE SWITCH (ON BRAKE PEDAL BRACKET)
CRUISE CONTROL SWITCH
CRUISE FUSE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGAGE INPUT
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL CLUSTER
OFF
OFF ON
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (FRONT LEFT SIDE OF ENGINE COMPT)
PPL
PPL VSS LOW
R/A
SET SW
STOP LAMPS FUSE
STOPLIGHT SWITCH (BRAKE PEDAL SUPPORT BRACKET)
VEHICLE SPEED SENSOR (VSS) (ON TRANSAXLE RIGHT AXLE CASE EXTENSION)
VSS
VSS OUTPUT
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> SET SW
