Buick Century VI (1997-2005) rear vertical adjuster motor wiring diagram
This page shows the only wiring diagram for the component.rear vertical adjuster motor, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear vertical adjuster motor wiring diagram (1 of 1)
BACK
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
ENTIRE SEAT
ENTIRE SEAT DOWN
ENTIRE SEAT UP
FOR- WARD
FOR- WARD BACK
FRONT HEIGHT FRONT HEIGHT
FRONT PASSENGER SEAT ADJUSTER MOTOR ASSEMBLY
FRONT PASSENGER SEAT ADJUSTER SWITCH
FRONT VERTICAL ADJUSTER MOTOR
GRN WIRE
HORIZONTAL ADJUSTER MOTOR
HOT AT ALL TIMES POWER SEATS CIRCUIT BREAKER
I/P FUSE BLOCK
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
REAR HEIGHT
REAR HEIGHT FRONT HEIGHT FRONT HEIGHT
REAR VERTICAL ADJUSTER MOTOR
TAN WIRE
YEL WIRE
Go to component -> 6-way power seat circuit -> REAR VERTICAL ADJUSTER MOTOR
