Buick Century VI (1997-2005) rear compartment lid ajar switch rear compartment lid lock release actuator Wiring diagram
This page shows the only wiring diagram for the component.rear compartment lid ajar switch rear compartment lid lock release actuator, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear compartment lid ajar switch rear compartment lid lock release actuator (1 of 1)
3 CM FROM
AUDIO AMPLIFIER (W/ AMP)
AUTOMATIC HEADLAMP RELAY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CENTER HIGH MOUNTED STOP LAMPS
CRUISE CONTROL MODULE
DRIVER INFORMATION DISPLAY SWITCH (REGAL) DATA LINK CONNECTOR (DLC)
DRIVER SEAT HEATER CONTROL MODULE DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT HEATER SWITCH PASSENGER SEAT HEATER SWITCH
DRIVER WINDOW MASTER SWITCH
DRIVER'S HEATED SEAT BACK ELEMENT
DRIVER'S HEATED SEAT THERMISTER DRIVER SEAT BELT SWITCH
EXC ONSTAR
EXC ONSTAR ONSTAR
FOG LAMP SWITCH (REGAL)
GROUND (ON STEERING COLUMN)
HEADLAMP DIMMER SWITCH
HEADLAMP SWITCH
IGNITION KEY ALARM SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT DOOR LOCK LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK (AJAR INDICATOR SWITCH)
LEFT REAR PARK LAMP LEFT REAR PARK LAMP LEFT LICENSE LAMP
LEFT ROOF RAIL COURTESY/ READING LAMP
NCA WIRE
ONSTAR
OUTSIDE REMOTE CONTROL REARVIEW MIRROR SWITCH
PASSENGER SEAT HEATER CONTROL MODULE
PASSENGER'S HEATED SEAT BACK ELEMENT
PASSENGER'S HEATED SEAT THERMISTOR PASSENGER SEAT ADJUSTER SWITCH
RADIO
RADIO ANTENNA MODULE
REAR COMPARTMENT LID AJAR SWITCH REAR COMPARTMENT LID LOCK RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE SWITCH
REAR WDO ANTENNA FIXED ANTENNA
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT BACK-UP LAMP RIGHT LICENSE LAMP LEFT BACK-UP LAMP
RIGHT FRONT DOOR LOCK (AJAR INDICATOR SWITCH)
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT WINDOW SWITCH
RIGHT REAR DOOR LOCK (AJAR INDICATOR SWITCH)
RIGHT REAR PARK LAMP RIGHT REAR PARK LAMP
RIGHT ROOF RAIL COURTESY/ READING LAMP LEFT VANITY MIRROR LAMP
RIGHT TAIL/ STOP/TURN SIGNAL LAMP RIGHT REAR SIDE MARKER LAMP FUEL PUMP
RIGHT VANITY MIRROR LAMP INSIDE REARVIEW MIRROR
SUNROOF MODULE
TAN WIRE
TIRE RESET SWITCH
TRACTION CONTROL SWITCH (REGAL) INSTRUMENT PANEL CLUSTER (IPC)
TURN SIGNAL/ HAZARD FLASHER MODULE
VEHICLE COMMUNICATIONS INTERFACE MODULE
W/ HEATED SEATS (PASS SEAT HARN, 20 CM FROM
W/O HEATED SEATS
WHT WIRE
WIND- SHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 2) -> REAR COMPARTMENT LID AJAR SWITCH REAR COMPARTMENT LID LOCK RELEASE ACTUATOR
