Buick Century VI (1997-2005) r/cmpt rel fuse Wiring diagrams
This page contains all the electrical diagrams for the component. r/cmpt rel fuse, in which he is found in the car Buick Century VI (1997-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram r/cmpt rel fuse (1 of 2)
BACK-UP LAMP RELAY (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
HOT AT ALL TIMES
LEFT BACK-UP LAMP
LT GRN WIRE
MIRRORS SYSTEM (AUTOMATIC DAY/NIGHT MIRROR)
ORG/ WIRE
R/CMPT REL FUSE
RIGHT BACK-UP LAMP
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER)
Go to component -> Back-up lamps circuit -> R/CMPT REL FUSE
Wiring diagram r/cmpt rel fuse (2 of 2)
1 13 3 9 W/O GPS W/ GPS
16 5 5 4 W/O GPS
BLK WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HEADLIGHT SENSOR (MIRROR SIDE)
HOT AT ALL TIMES
HOT IN RUN
HVAC FUSE
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
INSIDE REARVIEW MIRROR (DAY-NIGHT)
LOW REF
LT GRN WIRE
NCA WIRE
OFF ON
ORG/ WIRE
OUTSIDE REARVIEW MIRROR LOW REF SIGNAL
PARK/ NEUTRAL POSITON (PNP) SWITCH (ON TOP RIGHT REAR OF TRANSAXLE)
PNK WIRE
R/CMPT REL FUSE
RESETS TO DAYTIME HIGH REFLECTIVITY IN REVERSE MIRROR ON
SIGNAL
SOLID STATE
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER)
W/ GPS
W/ SUNROOF W/O SUNROOF
W/O HEATED SEATS W/ HEATED SEATS
Go to component -> Electrochromic mirror circuit -> R/CMPT REL FUSE
