Buick Century VI (1997-2005) radio, hvac, rfa, cel tel, cluster fuse Wiring diagrams

AM/FM ANT IN AUDIO AMPLIFIER (BELOW REAR SPEAKER SHELF, IN TRUNK) BARE BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE E, C DATA FRONT WINDOW ANTENNA GRID GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING) INFLATABLE RESTRAINT STEERING WHEEL CONTROL MODULE LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TWEETER SPEAKER LEFT RADIO CONTROL SWITCHES LEFT REAR SPEAKER LF AUDIO RF AUDIO LF AUDIO RR AUDIO RR AUDIO LR AUDIO LR AUDIO GROUND GROUND LF SPKR LF SPKR RR SPKR RR SPKR LT BLU WIRE LT BLU/BLK WIRE LT GRN (OR BLK/WHT) WIRE LT GRN WIRE LT GRN/BLK WIRE LT LT MID-RANGE MUTE NCA WIRE ORG/ WIRE ORG/BLK WIRE PPL RADIO RADIO ANTENNA MODULE (ON REAR WINDOW HEADER PANEL) RADIO FUSE RADIO PREM FUSE RADIO, HVAC, RFA, CEL TEL, CLUSTER FUSE REAR WINDOW ANTENNA GRID RED WIRE RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TWEETER SPEAKER RIGHT RADIO CONTROL SWITCHES RIGHT REAR SPEAKER RR RTN RR FEED LR FEED LR RTN SCAN SEEK DN SEEK UP SOURCE STRG CTRL SUB RTN SUB RTN SUB-WOOFER TAN WIRE USED) (NOT VEHICLE INTERFACE UNIT (VIU) (IN REAR COMPT, MOUNTED TO LEFT REAR WHEELHOUSE) VOL DN VOL UP W/ ADAPTIVE RECEPTION SYSTEM W/O ADAPTIVE RECEPTION SYSTEM WHT WIRE YEL WIRE

AM/FM ANT IN ARS BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE E, C DATA FRONT WINDOW ANTENNA GRID GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING) INFLATABLE RESTRAINT STEERING WHEEL CONTROL MODULE LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER LEFT RADIO CONTROL SWITCHES LEFT REAR SPEAKER LF SPKR LF SPKR RR SPKR RR SPKR LR SPKR LR SPKR RF SPKR RF SPKR GROUND BATTERY RAP PWR RADIO PWR ILLUM FUSE OUT LT BLU WIRE LT GRN (OR BLK/WHT) WIRE LT GRN WIRE MUTE NCA WIRE NOT USED ORG/ WIRE RADIO RADIO ANTENNA MODULE (ON REAR WINDOW HEADER PANEL) RADIO FUSE RADIO, HVAC, RFA, CEL TEL, CLUSTER FUSE REAR WINDOW ANTENNA GRID RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT RADIO CONTROL SWITCHES RIGHT REAR SPEAKER SCAN SEEK DN SEEK UP SOURCE STRG CTRL TAN WIRE VOL DN VOL UP W/ ADAPTIVE RECEPTION SYSTEM W/O ADAPTIVE RECEPTION SYSTEM WHT WIRE YEL WIRE
