Buick Century VI (1997-2005) passenger heated seat back element Wiring diagram
This page shows the only wiring diagram for the component.passenger heated seat back element, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger heated seat back element (1 of 1)
BLK WIRE
BRN WIRE
DRIVER HEATED SEAT BACK ELEMENT
DRIVER HEATED SEAT CONTROL MODULE
DRIVER HEATED SEAT CUSHION COVER
DRIVER HEATED SEAT CUSHION ELEMENT
DRIVER HEATED SEAT SWITCH
DRIVER HEATED SEAT THERMISTOR
FRONT PASSENGER HEATED SEAT CONTROL MODULE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HVAC FUSE
I/P FUSE BLOCK
LH HEATED SEAT FUSE
LO/HI INPUT
LT BLU WIRE
LT BLU/BLK WIRE
NCA WIRE
ON INPUT
ORG/ WIRE
PASSENGER HEATED SEAT BACK ELEMENT
PASSENGER HEATED SEAT CUSHION COVER PASSENGER HEATED SEAT THERMISTOR
PASSENGER HEATED SEAT CUSHION ELEMENT
PASSENGER HEATED SEAT SWITCH
PNK WIRE
RED/WHT WIRE
RH HEATED SEAT FUSE
SENSOR INPUT
YEL/BLK WIRE
Go to component -> Heated seats circuit -> PASSENGER HEATED SEAT BACK ELEMENT
