Buick Century VI (1997-2005) outside rearview mirror low ref signal Wiring diagram
This page shows the only wiring diagram for the component.outside rearview mirror low ref signal, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside rearview mirror low ref signal (1 of 1)
1 13 3 9 W/O GPS W/ GPS
16 5 5 4 W/O GPS
BLK WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HEADLIGHT SENSOR (MIRROR SIDE)
HOT AT ALL TIMES
HOT IN RUN
HVAC FUSE
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
INSIDE REARVIEW MIRROR (DAY-NIGHT)
LOW REF
LT GRN WIRE
NCA WIRE
OFF ON
ORG/ WIRE
OUTSIDE REARVIEW MIRROR LOW REF SIGNAL
PARK/ NEUTRAL POSITON (PNP) SWITCH (ON TOP RIGHT REAR OF TRANSAXLE)
PNK WIRE
R/CMPT REL FUSE
RESETS TO DAYTIME HIGH REFLECTIVITY IN REVERSE MIRROR ON
SIGNAL
SOLID STATE
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER)
W/ GPS
W/ SUNROOF W/O SUNROOF
W/O HEATED SEATS W/ HEATED SEATS
Go to component -> Electrochromic mirror circuit -> OUTSIDE REARVIEW MIRROR LOW REF SIGNAL
