Buick Century VI (1997-2005) lock off Wiring diagrams
This page contains all the electrical diagrams for the component. lock off, in which he is found in the car Buick Century VI (1997-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lock off (1 of 2)
A/T SHIFT LOCK CONTROL SWITCH
BCM ACC FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH)
BREAKOUT)
BRN (OR DK BLU) WIRE
BRN WIRE
CRANK SIGNAL BCM, CLUSTER FUSE
DK BLU WIRE
DK GRN WIRE
FROM GEN FUSE 21 (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM INADV POWER BUS FUSE (DIAGRAM 1 OF 3)
FROM R HEATED SEAT FUSE DIAGRAM (1 OF 3)
FUSE 5
FUSE 8
FUSE BLOCK, UNDER- HOOD
FUSE BLOCK- I/P
FUSE BLOCK- UNDERHOOD
GRY WIRE
HEATER- A/C CONTROL CRUISE CONTROL SWITCH CRUISE CONTROL MODULE
HVAC CONTROL MODULE RIGHT AIR TEMPERATURE ACTUATOR
HVAC FUSE
I/P HARN, RIGHT SIDE OF STEERING COLUMN, 13 CM FROM INSTRUMENT CLUSTER BREAKOUT)
IGN 0,CLUSTER, PCM, BCM FUSE
IGNITION SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL BREAKOUT)
INSIDE REARVIEW MIRROR
INSTRUMENT PANEL CLUSTER (IPC) BODY CONTROL MODULE (BCM)
LEFT AIR TEMPERATURE ACTUATOR
LEFT RADIO CONTROL SWITCH LEFT FRONT WINDOW SWITCH SUNROOF MODULE
LOCK
LOCK OFF
LOW BLOWER FUSE CRUISE FUSE
NCA WIRE
OFF
ONSTAR FUSE
ORG/ WIRE
PARK LOCK FUSE (REGAL)
PASSENGER SEAT HEATER SWITCH DRIVER SEAT HEATER SWITCH
PNK WIRE
POWER DROP CONNECTOR
POWER DROP FUSE
POWERTRAIN CONTROL MODULE (PCM)
PPL
PPL PPL
PPL/ PPL/ PPL/
PWR WINDOWS PWR SUNROOF CIRCUIT BREAKER
RADIO
RADIO FUSE
RADIO FUSE (W/O RAP)
REAR WINDOW DEFOGGER RELAY
RED WIRE
REGAL
RETAINED ACCESSORY POWER (RAP) RELAY
RUN WIRE
TO CRANK SIGNAL FUSE (DIAGRAM 2 OF 3)
TO IGN MAIN RELAY 13 (DIAGRAM 3 OF 3)
TO LOW BLOWER FUSE (DIAGRAM 2 OF 3)
VACUUM CONTROL ASSEMBLY CRUISE CONTROL RELEASE SWITCH
VEHICLE COMMUNI- CATIONS INTERFACE MODULE
W/ ELECTRIC O/S MIRRORS
W/ FOLD AWAY MIRRORS
W/ RAP
W/ RAP W/O RAP
W/ SUN ROOF
W/O RAP
WHT WIRE
WINDSHIELD WIPER MOTOR WIND- SHIELD WIPER/ WASHER SWITCH
WIPER FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> LOCK OFF
Wiring diagram lock off (2 of 2)
BATTERY
BLK WIRE
BULB TEST
BULB TEST LOCK
CHARGING CIRCUIT (FUSIBLE LINK)
CRANK
CRANK FUSE
CRANK RELAY
CRANK SIGNAL BCM, CLUSTER FUSE
HOLD- IN COIL
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
IGN 1 FUSE
IGNITION SWITCH
LOCK OFF
NCA WIRE
OFF
PCM BCM IGN RELAY FUSE
PNK WIRE
PPL
PULL- IN COIL
RED WIRE
RUN WIRE
STARTER
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT FRONT STRUT TOWER)
YEL WIRE
YEL/BLK WIRE
Go to component -> Starting circuit -> LOCK OFF
