Buick Century VI (1997-2005) left roof rail courtesy/ reading lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left roof rail courtesy/ reading lamp, in which he is found in the car Buick Century VI (1997-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left roof rail courtesy/ reading lamp (1 of 2)
BLK WIRE
BODY COMPUTER MODULE (BCM) (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
DIODE
DOME LAMP
EXCEPT BASE BASE
GRY WIRE
INSIDE REAR VIEW MIRROR
LEFT ROOF RAIL COURTESY/ READING LAMP
LEFT VANITY MIRROR LAMP
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID AJAR SWITCH
REAR COMPARTMENT OCCUPANT SENSOR (AT LEFT SIDE OF REAR COMPT)
RED/BLK WIRE
RIGHT ROOF RAIL COURTESY/ READING LAMP
RIGHT VANITY MIRROR LAMP
W/ ENTRAPMENT PROTECTION
W/ ONSTAR W/O ONSTAR
W/O ENTRAPMENT PROTECTION
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT ROOF RAIL COURTESY/ READING LAMP
Wiring diagram left roof rail courtesy/ reading lamp (2 of 2)
3 CM FROM
AUDIO AMPLIFIER (W/ AMP)
AUTOMATIC HEADLAMP RELAY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CENTER HIGH MOUNTED STOP LAMPS
CRUISE CONTROL MODULE
DRIVER INFORMATION DISPLAY SWITCH (REGAL) DATA LINK CONNECTOR (DLC)
DRIVER SEAT HEATER CONTROL MODULE DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT HEATER SWITCH PASSENGER SEAT HEATER SWITCH
DRIVER WINDOW MASTER SWITCH
DRIVER'S HEATED SEAT BACK ELEMENT
DRIVER'S HEATED SEAT THERMISTER DRIVER SEAT BELT SWITCH
EXC ONSTAR
EXC ONSTAR ONSTAR
FOG LAMP SWITCH (REGAL)
GROUND (ON STEERING COLUMN)
HEADLAMP DIMMER SWITCH
HEADLAMP SWITCH
IGNITION KEY ALARM SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT DOOR LOCK LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK (AJAR INDICATOR SWITCH)
LEFT REAR PARK LAMP LEFT REAR PARK LAMP LEFT LICENSE LAMP
LEFT ROOF RAIL COURTESY/ READING LAMP
NCA WIRE
ONSTAR
OUTSIDE REMOTE CONTROL REARVIEW MIRROR SWITCH
PASSENGER SEAT HEATER CONTROL MODULE
PASSENGER'S HEATED SEAT BACK ELEMENT
PASSENGER'S HEATED SEAT THERMISTOR PASSENGER SEAT ADJUSTER SWITCH
RADIO
RADIO ANTENNA MODULE
REAR COMPARTMENT LID AJAR SWITCH REAR COMPARTMENT LID LOCK RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE SWITCH
REAR WDO ANTENNA FIXED ANTENNA
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT BACK-UP LAMP RIGHT LICENSE LAMP LEFT BACK-UP LAMP
RIGHT FRONT DOOR LOCK (AJAR INDICATOR SWITCH)
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT WINDOW SWITCH
RIGHT REAR DOOR LOCK (AJAR INDICATOR SWITCH)
RIGHT REAR PARK LAMP RIGHT REAR PARK LAMP
RIGHT ROOF RAIL COURTESY/ READING LAMP LEFT VANITY MIRROR LAMP
RIGHT TAIL/ STOP/TURN SIGNAL LAMP RIGHT REAR SIDE MARKER LAMP FUEL PUMP
RIGHT VANITY MIRROR LAMP INSIDE REARVIEW MIRROR
SUNROOF MODULE
TAN WIRE
TIRE RESET SWITCH
TRACTION CONTROL SWITCH (REGAL) INSTRUMENT PANEL CLUSTER (IPC)
TURN SIGNAL/ HAZARD FLASHER MODULE
VEHICLE COMMUNICATIONS INTERFACE MODULE
W/ HEATED SEATS (PASS SEAT HARN, 20 CM FROM
W/O HEATED SEATS
WHT WIRE
WIND- SHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 2) -> LEFT ROOF RAIL COURTESY/ READING LAMP
