Buick Century VI (1997-2005) ign main relay 13 Wiring diagram
This page shows the only wiring diagram for the component.ign main relay 13, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign main relay 13 (1 of 1)
3.8L 3.1L
A/C CLUTCH RELAY 15
A/T SHIFT CONTROL SWITCH (REGAL)
ABS FUSE
AIR BAG FUSE
AUTOMATIC TRANSAXLE (LEFT OF STARTER, ON TRANS- AXLE STUD)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE- TO-SHIFT RELAY
BTSI PARK LOCK FUSE
CLUSTER FUSE
CRANK RELAY 11
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ELEK IGN FUSE 25 OXY SEN FUSE 29
ENG EMIS FUSE 30
EVAPORATIVE EMISSIONS (EVAP) CANISTER PURGE SOLENOID VALVE
EVAPORATIVE EMISSIONS (EVAP) CANISTER VENT SOLENOID VALVE
F/INJ FUSE 28
FROM IGN 1 FUSE 5
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3 FUEL INJECTOR 5
FUEL INJECTOR 4
FUEL INJECTOR 6
FUSE BLOCK- I/P
FUSE BLOCK- UNDERHOOD
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 1 IGNITION CONTROL MODULE (ICM)
IGN MAIN RELAY 13
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL CLUSTER (IPC)
NCA WIRE
PCM,BCM U/H RELAY FUSE
PNK MASS AIRFLOW (MAF) SENSOR WIRE
PNK PNK WIRE
PNK STOPLAMP SWITCH WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
REGAL VIN K
SECONDARY AIR INJECTION BYPASS VALVE SOLENOID
STOPLAMP SWITCH (CENTURY)
SUPERCHARGER BYPASS VALVE (3.8L)
TRANS FUSE 26
TURN SIGNAL/ HAZARD FLASHER MODULE
TURN SIGNALS, CORN LPS FUSE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> IGN MAIN RELAY 13
