Buick Century VI (1997-2005) hot in accy, run,, retained accessory power Wiring diagram
This page shows the only wiring diagram for the component.hot in accy, run,, retained accessory power, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in accy, run,, retained accessory power (1 of 1)
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CLOSE
CLOSE OPEN
DK BLU WIRE
DK BLU/RED WIRE
HOT IN ACCY, RUN,, RETAINED ACCESSORY POWER
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
OPEN GND
ORG/ WIRE
POS 2 POS 1 POS 3 GND GND
POWER WINDOWS SYSTEM
PPL
PWR WINDOWS PWR SUN ROOF CIRCUIT BREAKER
RED WIRE
SUN ROOF MODULE (CENTER REAR OF SUN ROOF)
SUN ROOF MOTOR (CENTER REAR OF SUN ROOF MODULE)
SUN ROOF SWITCH
SUNROOF LIMIT SWITCH ASSEMBLY (IN SUNROOF MOTOR TRANSMISSION
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> HOT IN ACCY, RUN,, RETAINED ACCESSORY POWER
