Buick Century VI (1997-2005) (engine harn, front of engine compt, Wiring diagram
This page shows the only wiring diagram for the component.(engine harn, front of engine compt,, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (engine harn, front of engine compt, (1 of 1)
39 22 27 34 CLUTCH RLY CTRL CLUTCH REQUEST A/C PRESS SIGNAL 5 VOLT REF
58 80 CLASS 2 SER DATA LOW REF
A/C CLU DIODE
A/C CLUTCH FUSE 23
A/C CLUTCH RELAY 15
A/C COMPRESSOR CLUTCH
A/C REFRIGERENT PRESSURE SENSOR (LEFT FRONT STRUT TOWER, ON A/C LIQUID LINE)
AUTO A/C MANUAL A/C
BLK WIRE
BREAKOUT)
BRN WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HVAC CONTROL MODULE
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) HVAC FUSE
IGN MAIN RELAY (CLOSED IN RUN OR START)
IGNITION BATTERY A/C REQUEST SERIAL DATA GROUND
ORG/ WIRE
RDO, HVAC, RFA CLSTR, CEL TEL FUSE
RED/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
W/ AUTO A/C
W/ MANUAL A/C
WHT WIRE
Go to component -> Compressor circuit -> (ENGINE HARN, FRONT OF ENGINE COMPT,
