Buick Century VI (1997-2005) dr unlk sw in dr lock sw in Wiring diagram
This page shows the only wiring diagram for the component.dr unlk sw in dr lock sw in, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dr unlk sw in dr lock sw in (1 of 1)
BATTERY
BCM FUSE BCM PWR FUSE
BLK WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
BRN WIRE
DOOR LOCK FUSE
DR UNLK SW IN DR LOCK SW IN
DRIVER DOOR LOCK SWITCH
FRONT PASSENGER DOOR LOCK SWITCH
GROUND
GROUND BATTERY (B+) DRIVER DR UNLK ALL DRS LOCK PASS DRS UNLK BATTERY (B+)
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT OF DASH IN RIGHT DOOR OPENING)
LEFT FRONT DOOR LOCK
LEFT REAR DOOR LOCK
LOCK
LT GRN WIRE
OLDSMOBILE
ORG/ WIRE
ORG/BLK WIRE
POWER DOOR BREAKOUT)
RADIO, HVAC, RFA, CLUSTER, DATA LINK FUSE
RED/BLK WIRE
RIGHT FRONT DOOR LOCK
RIGHT REAR DOOR LOCK
SERIAL DATA
TAN WIRE
TRUNK LID REL
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNLOCK
Go to component -> Power door locks circuit -> DR UNLK SW IN DR LOCK SW IN
