Buick Century VI (1997-2005) day/night mirror system Wiring diagram
This page shows the only wiring diagram for the component.day/night mirror system, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram day/night mirror system (1 of 1)
BLK WIRE
DAY/NIGHT MIRROR SYSTEM
DRIVER OUTSIDE REARVIEW MIRROR
ECB
ECB ECB
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
LEFT MIRROR RIGHT MIRROR
LOW REF SIGNAL
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PNK WIRE
POWER MIRRORS FUSE
PPL
PPL/WHT WIRE
RED/WHT WIRE
RIGHT/ LEFT MOTOR
RIGHT/ LEFT MOTOR UP/ DOWN MOTOR
UP DN
UP DN UP
UP/ DOWN MOTOR
WHT RED/ WIRE
WHT WIRE
Go to component -> Power mirrors circuit -> DAY/NIGHT MIRROR SYSTEM
