Buick Century VI (1997-2005) crank relay 11 Wiring diagrams
This page contains all the electrical diagrams for the component. crank relay 11, in which he is found in the car Buick Century VI (1997-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram crank relay 11 (1 of 2)
A/C CLUTCH FUSE 23
A/C CLUTCH RELAY 15
ABS FUSE 1
ACCESSORY POWER OUTLET
AUDIO AMPLIFIER
BACK-UP LAMP RELAY (REGAL)
BATT 1 FUSE 7
BATT 3 FUSE 3 BATT 2 FUSE 4
BATTERY
BCM PWR FUSE
BLK WIRE
BLOWER MOTOR CONTROL PROCESSOR BLOWER MOTOR RESISTOR ASSEMBLY
BODY CONTROL MODULE (BCM)
BODY CONTROL MODULE (BCM) OUTSIDE REARVIEW MIRROR SWITCH
BREAKOUT)
CIGAR LIGHTER
CIGAR LTR FUSE
COOL FAN 1 FUSE 6
COOL FAN 1 RELAY 12
COOL FAN 2 FUSE 24
COOL FAN 2 RELAY 9
COOL FAN 3 RELAY
CRANK FUSE 2
CRANK RELAY 11
DATA LINK CONNECTOR (DLC)
DRIVER HEATED SEAT CONTROL MODULE
DRIVER SEAT ADJUSTER SWITCH
ECM FUSE 22
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
F/PMP FUSE 35
F/PMP RELAY 19
F/PMP SPD CONT RELAY 18
FOG LAMP RELAY 17
FOG LP FUSE 31
FROM BATT 2 FUSE 4 (DIAGRAM 1 OF 3)
FROM HORN FUSE 27 (DIAGRAM 1 OF 3)
FUSE BLOCK- I/P
FUSE BLOCK- UNDERHOOD
FUSIBLE LINK (10 GA-RUST)
GEN FUSE 21
GENERATOR
HAZARD FUSE
HDLP L FUSE 36
HDLP R FUSE 32
HEADLAMP RELAY
HEADLAMP SWITCH PARK LAMP RELAY
HIGH BLOWER FUSE
HORN FUSE 27
HORN RELAY 16
HVAC CONTROL MODULE RADIO
INADV POWER BUS FUSE
INSTRUMENT PANEL CLUSTER (IPC)
L HEATED SEAT FUSE
LEFT HEADLAMP
LP PARK FUSE 34
NCA WIRE
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH (CENTURY)
PASSENGER FRONT HEATED SEAT CONTROL MODULE
PASSENGER FRONT SEAT ADJUSTER SWITCH
POWER DROP CONNECTOR
POWER MIRRORS FUSE DOOR LOCKS FUSE
POWERTRAIN CONTROL MODULE (PCM)
R/CMPT REL FUSE 33
RADIO PREM SOUND FUSE
RDO,HVAC RFA,CLUSTER DATA LINK FUSE
REAR COMPARTMENT LID RELEASE RELAY
REAR DEFOG CIRCUIT BREAKER POWER SEAT CIRCUIT BREAKER
REAR WINDOW DEFOGGER RELAY
RED WIRE
REGAL
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT HEADLAMP
STARTER
STOP LAMPS FUSE
STOPLAMP SWITCH
TO HDLP L FUSE 36 (DIAGRAM 1 OF 3)
TO HIGH BLOWER FUSE (DIAGRAM 1 OF 3)
TO IGN 2 FUSE 8 (DIAGRAM 2 OF 3)
TO ONSTAR FUSE, DIAGRAM (2 OF 3) R HEATED SEAT FUSE
TO RETAINED ACCESSORY POWER (RAP) RELAY (DIAGRAM 2 OF 3)
TURN SIGNAL/ HAZARD FLASHER MODULE
Go to component -> Power distribution circuit (1 of 3) -> CRANK RELAY 11
Wiring diagram crank relay 11 (2 of 2)
3.8L 3.1L
A/C CLUTCH RELAY 15
A/T SHIFT CONTROL SWITCH (REGAL)
ABS FUSE
AIR BAG FUSE
AUTOMATIC TRANSAXLE (LEFT OF STARTER, ON TRANS- AXLE STUD)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE- TO-SHIFT RELAY
BTSI PARK LOCK FUSE
CLUSTER FUSE
CRANK RELAY 11
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ELEK IGN FUSE 25 OXY SEN FUSE 29
ENG EMIS FUSE 30
EVAPORATIVE EMISSIONS (EVAP) CANISTER PURGE SOLENOID VALVE
EVAPORATIVE EMISSIONS (EVAP) CANISTER VENT SOLENOID VALVE
F/INJ FUSE 28
FROM IGN 1 FUSE 5
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3 FUEL INJECTOR 5
FUEL INJECTOR 4
FUEL INJECTOR 6
FUSE BLOCK- I/P
FUSE BLOCK- UNDERHOOD
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 1 IGNITION CONTROL MODULE (ICM)
IGN MAIN RELAY 13
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL CLUSTER (IPC)
NCA WIRE
PCM,BCM U/H RELAY FUSE
PNK MASS AIRFLOW (MAF) SENSOR WIRE
PNK PNK WIRE
PNK STOPLAMP SWITCH WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
REGAL VIN K
SECONDARY AIR INJECTION BYPASS VALVE SOLENOID
STOPLAMP SWITCH (CENTURY)
SUPERCHARGER BYPASS VALVE (3.8L)
TRANS FUSE 26
TURN SIGNAL/ HAZARD FLASHER MODULE
TURN SIGNALS, CORN LPS FUSE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> CRANK RELAY 11
