Buick Century VI (1997-2005) court lmps on door open input driver dr open Wiring diagram
This page shows the only wiring diagram for the component.court lmps on door open input driver dr open, which is found in the car Buick Century VI (1997-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram court lmps on door open input driver dr open (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
COURT LMPS FEED
COURT LMPS ON DOOR OPEN INPUT DRIVER DR OPEN
DK BLU WIRE
DK BLU/WHT WIRE
DRIVER DOOR LOCK
FRONT PASSENGER DOOR LOCK
HEADLAMP SWITCH DOME
HOT AT ALL TIMES
I/P COMPART- MENT LAMP/ SWITCH
I/P FUSE BLOCK
INADV POWER BUS FUSE
LEFT COURTESY LAMP
LEFT REAR DOOR LOCK
LT GRN WIRE
OFF LO HI
ORG/ WIRE
REGAL, CENTURY CUSTOM
RIGHT COURTESY LAMP
RIGHT REAR DOOR LOCK
SERIAL DATA
THEATER DIM 1 THEATER DIM (GRD)
WHT WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> COURT LMPS ON DOOR OPEN INPUT DRIVER DR OPEN
