Buick Century VI (1997-2005) a/c clu diode Wiring diagrams
This page contains all the electrical diagrams for the component. a/c clu diode, in which he is found in the car Buick Century VI (1997-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c clu diode (1 of 3)
39 22 27 34 CLUTCH RLY CTRL CLUTCH REQUEST A/C PRESS SIGNAL 5 VOLT REF
58 80 CLASS 2 SER DATA LOW REF
A/C CLU DIODE
A/C CLUTCH FUSE 23
A/C CLUTCH RELAY 15
A/C COMPRESSOR CLUTCH
A/C REFRIGERENT PRESSURE SENSOR (LEFT FRONT STRUT TOWER, ON A/C LIQUID LINE)
AUTO A/C MANUAL A/C
BLK WIRE
BREAKOUT)
BRN WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HVAC CONTROL MODULE
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) HVAC FUSE
IGN MAIN RELAY (CLOSED IN RUN OR START)
IGNITION BATTERY A/C REQUEST SERIAL DATA GROUND
ORG/ WIRE
RDO, HVAC, RFA CLSTR, CEL TEL FUSE
RED/BLK WIRE
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
W/ AUTO A/C
W/ MANUAL A/C
WHT WIRE
Go to component -> Compressor circuit -> A/C CLU DIODE
Wiring diagram a/c clu diode (2 of 3)
A/C CLU DIODE
A/C COMPRESSOR CLUTCH
AUTOMATIC TRANSMISSION
AUXILIARY POWER OUTLET (CENTURY)
AUXILIARY POWER OUTLET (REGAL)
BATTERY
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR CONTROL PROCESSOR
BLOWER MOTOR RESISTOR ASSEMBLY
CIGAR LIGHTER (CENTURY) ASHTRAY LAMP (CENTURY)
CIGAR LIGHTER (REGAL)
COOL FAN 2 RELAY
DATA LINK CONNECTOR (DLC)
ELECTRONIC BRAKE CONTROL MODULE
ENG COMPT, AT BASE OF BATTERY)
ENGINE OIL LEVEL SENSOR
ENGINE OIL PRESSURE SWITCH
F/PUMP RELAY
FUSE BLOCK- UNDERHOOD
HEATED OXYGEN SENSOR 2
HORNS
I/P COMPARTMENT LAMP SWITCH
IGN MAIN RELAY
IGNITION CONTROL MODULE (ICM)
IGNITION LOCK CYLINDER CONTROL ACTUATOR (REGAL)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT AIR TEMPERATURE ACTUATOR
LEFT CORNERING LAMP
LEFT FOG LAMP (REGAL)
LEFT HEADLAMP
LEFT PARK/ TURN SIGNAL LAMP
LEFT SIDE MARKER LAMP
LEFT STEERING WHEEL CONTROLS
MASS AIRFLOW (MAF) SENSOR
NCA WIRE
POWER DROP CONNECTOR
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
REGAL
RIGHT AIR TEMPERATURE ACTUATOR HVAC CONTROL MODULE
RIGHT COOLING FAN HEATED OXYGEN SENSOR 1
RIGHT CORNERING LAMP
RIGHT FOG LAMP (REGAL)
RIGHT HEADLAMP
RIGHT PARK/ TURN SIGNAL LAMP
RIGHT SIDE MARKER LAMP
RIGHT STEERING WHEEL CONTROLS
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER FLUID PUMP
Go to component -> Ground distribution circuit (1 of 2) -> A/C CLU DIODE
Wiring diagram a/c clu diode (3 of 3)
3.8L 3.1L
A/C CLU DIODE
A/C CLUTCH RELAY 15
A/C COMPRESSOR CLUTCH
A/C REFRIGERENT PRESSURE SENSOR (AT LEFT FRONT STRUT TOWER, ON A/C LIQUID LINE)
BLK WIRE
BREAKOUT)
BRN WIRE
COOL FAN 1 FUSE COOL FAN 2 FUSE A/C CLUTCH FUSE 23
COOL FAN 1 RELAY
COOL FAN 2 RELAY
COOL FAN 3 RELAY
DEFOGGER SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRVR TEMP CTRL
ENGINE CONTROLS SYSTEM
FAN OFF INPUT A/C REQUEST SIG IGNITION DEFOGGER ON PASS TEMP CTRL
GRY WIRE
HIGH BLOWER FUSE
HIGH BLOWER RELAY
HOT AT ALL TIMES
HOT IN RUN
HVAC CONTROL MODULE
HVAC FUSE
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
IGN
IGN MAIN RELAY (CLOSED IN RUN OR START)
INTERIOR LIGHTS GROUND BATTERY LAMP DIM SIG
LEFT COOLING FAN BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH, IN HVAC MODULE)
LEFT COOLING FAN DIODE (3.1L)
LOW BLOWER FUSE
LT BLU WIRE
NCA WIRE
OFF LO
ORG/ WIRE
ORG/BLK WIRE
POS
PPL
RDO, HVAC, RFA CLSTR, CEL TEL FUSE
RED/BLK WIRE
RIGHT AIR TEMPERATURE ACTUATOR (RIGHT SIDE OF HVAC MODULE)
RIGHT COOLING FAN DIODE (3.1L)
TAN WIRE
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT, MOUNTED TO STRUT TOWER)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit -> A/C CLU DIODE
