Buick Century V (1982-1996) vss signal ppl vss return wiring diagram
This page shows the only wiring diagram for the component.vss signal ppl vss return, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
vss signal ppl vss return wiring diagram (1 of 1)
4000 PULSES/MILE
AUTOMATIC TRANSAXLE (LOWER LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BRAKE INPUT
BRAKE SW (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CRUISE CONTROL MODULE (LEFT FRONT SHOCK TOWER)
CRUISE IND
CRUISE ON/OFF INPUT
CRUISE STATUS
CRUISE SW
DK BLU WIRE
DK GRN WIRE
FAN/ALT FUSE
FUSE BLOCK
GAGES FUSE
GROUND PNK IGNITION INPUT WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER (BUICK CENTURY ONLY)
MULTI-FUNCTION ALARM MODULE
MULTI-FUNCTION LEVER
OFF
OFF ON
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF I/P)
PPL
PPL BRAKE SW OUTPUT
PPL TORQUE CONVERTER CLUTCH SOLENOID
R/A
RESUME/ACCEL INPUT PPL BRAKE INPUT
SET SW
SET/COAST INPUT
STOP/HAZ FUSE
VEHICLE SPEED ENABLE
VEHICLE SPEED INPUT
VEHICLE SPEED SENSOR (VSS) (LOWER RIGHT REAR OF ENGINE, ON TRANSAXLE)
VSS SIGNAL PPL VSS RETURN
WHT WIRE
YEL WIRE
