Buick Century V (1982-1996) tailgate release relay wiring diagram
This page shows the only wiring diagram for the component.tailgate release relay, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
tailgate release relay wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
FUSE BLOCK
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK/ NEUTRAL POSITION SWITCH
PNK WIRE
PWR/ACC BREAKER
REMOTE KEYLESS ENTRY MODULE (LEFT CENTER OF LUGGAGE COMPT)
TAILGATE RELEASE RELAY
TAILGATE RELEASE SOLENOID
TAILGATE RELEASE SWITCH
TURN-B/U FUSE
Go to component -> Tailgate release circuit, wagon -> TAILGATE RELEASE RELAY
