Buick Century V (1982-1996) right back-up lt license lt Wiring diagram
This page shows the only wiring diagram for the component.right back-up lt license lt, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right back-up lt license lt (1 of 1)
BACK-UP LTS
BLK WIRE
BUICK SEDAN
BUICK WAGON
CAPACITOR A
DIAGNOSTIC ENERGY RESERVE MODULE
FORWARD DISCRIMINATING SENSOR
FUEL TANK UNIT
HIGH LEVEL STOP LT
HIGH LEVEL STOP LT IN-LINE RESISTOR LEFT BACK-UP LT
HIGH LEVEL STOP LT SAFETY BELT SW
LEFT BACK-UP LT RIGHT BACK-UP LT
LEFT DOOR MIRROR SW
LEFT REAR MARKER LT
LEFT REAR MARKER LT LEFT REAR TAIL/ STOP/TURN LT
LEFT REAR TAIL/ STOP/TURN LT
LEFT RECLINER SW
LEFT TAIL LT
LICENSE LT
OLDS SEDAN
PASSENGER COMPARTMENT DISCRIMINATING SENSOR
POWER SEAT SW
PROGRAM CONN
REAR DOME LT
REAR WASHER PUMP
REAR WIPER MODULE
REAR WIPER/ WASHER CONTROL SW
REMOTE KEYLESS ENTRY MODULE
RIGHT BACK-UP LT LICENSE LT
RIGHT REAR MARKER LT
RIGHT REAR TAIL/ STOP/TURN LT
RIGHT RECLINER SW
RIGHT TAIL LT
SEDAN
W/ AUO
W/O LUGGAGE CARRIER W/ LUGGAGE CARRIER
WAGON
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> RIGHT BACK-UP LT LICENSE LT
