Buick Century V (1982-1996) pulse width modulated output control Wiring diagram
This page shows the only wiring diagram for the component.pulse width modulated output control, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pulse width modulated output control (1 of 1)
1.0 K
32 K
490 K
7 TO 15 OHMS
BLK WIRE
BRN WIRE
DATA LINK CONNECTOR
DK GRN WIRE
EVO ENABLE
FAN/ALT FUSE 10 AMP
FUSE BLOCK
GROUND
HOT IN RUN
IGNITION INPUT
LT BLU WIRE
LT GRN WIRE
ORG/BLK WIRE
POWER STEERING RESERVOIR VES SOLENOID ACTUATOR
POWERTRAIN CONTROL MODULE
PULSE WIDTH MODULATED OUTPUT CONTROL
SOLID STATE
SPEED INPUT
STEERING WHEEL ROTATING SENSOR
STEERING WHEEL ROTATION SENSE
V REF LO
VARIABLE EFFORT STEERING CONTROL MODULE
VEHICLE SPEED OUTPUT
VEHICLE SPEED SENSOR
WHT WIRE
Go to component -> Electronic power steering circuit -> PULSE WIDTH MODULATED OUTPUT CONTROL
