Buick Century V (1982-1996) ppl warning systems Wiring diagram
This page shows the only wiring diagram for the component.ppl warning systems, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl warning systems (1 of 1)
392 OHM
BACKUP LIGHTS CIRCUIT PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CONVENIENCE CENTER (RIGHT I/P, RIGHT OF I/P COMPT)
DAYTIME RUNNING LIGHTS MODULE (BEHIND CENTER OF I/P)
DK DK
FUSE
FUSE BLOCK (BEHIND RIGHT I/P)
GRN WIRE
HAZARD
HAZARD FLASHER
HEAD OFF PARK
HIGH LEVEL STOP LIGHT
HIGH LEVEL STOP LIGHT IN-LINE RESISTOR (IN LIFTGATE, NEAR PASS THRU)
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
INSTRUMENT CLUSTER
LEFT FRONT MARKER LIGHT
LEFT FRONT PARK/ TURN LIGHT
LEFT REAR MARKER LIGHT
LEFT REAR TAIL/ STOP/ TURN LIGHTS
LEFT TURN IND. LT
LEFT TURN SWITCH
LICENSE LIGHT
LIGHT SWITCH PARK LAMPS CTRL
NCA WIRE
NORMAL
ORG/ WIRE
PNK WIRE
PPL
PPL WARNING SYSTEMS
RADIO
RIGHT FRONT MARKER LIGHT
RIGHT FRONT PARK/ TURN LIGHT
RIGHT REAR MARKER LIGHT
RIGHT REAR TAIL/ STOP/ TURN LIGHTS
RIGHT TURN IND
RIGHT TURN SWITCH
STOP HAZ
STOP LAMP BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
TAIL FUSE
TURN B/U
TURN FLASHER
TURN/ HAZARD SWITCH ASSEMBLY
UNDERHOOD LIGHT
W/DRL ONLY
WHT WIRE
YEL WIRE
Go to component -> Exterior light circuit, wagon -> PPL WARNING SYSTEMS
