Buick Century V (1982-1996) multi- function alarm module safety belt input Wiring diagram
This page shows the only wiring diagram for the component.multi- function alarm module safety belt input, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi- function alarm module safety belt input (1 of 1)
2.49
5.1
8.45
AIR BAG FUSE
ANTI-LOCK BRAKES
ARMING SENSOR (LEFT OF PCM)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CONVENIENCE CENTER (BEHIND LEFT SIDE OF I/P, NEAR SHROUD)
DIAGNOSTIC ENERGY RESERVE MODULE (DERM) (BEHIND HVAC CONTROL HEAD)
DK GRN WIRE
DRIVER SEAT BELT
DRIVER SIDE "HIGH" PPL CRANK INPUT
DRIVER SIDE "LOW"
DRIVER SOURCE SENSE
FORWARD DISCRIMINATING SENSOR (FORWARD OF CONDENSOR, BELOW HOOD LATCH)
GROUND
GRY WIRE
GUAGES FUSE
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
IGN 1
INFLATOR MODULE
INSTRUMENT CLUSTER AIR BAG IND
LT GRN WIRE
MULTI- FUNCTION ALARM MODULE SAFETY BELT INPUT
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL DATA LINK CONN (DLC) (BELOW LEFT SIDE OF I/P, NEAR STEERING COLUMN)
PPL DIAG REQUEST INPUT
REDUNDANT GROUND
SEAT BELT SW-
SERIAL DATA LINE
SHORTING BAR
SIR COIL ASSEMBLY (INSIDE STEERING WHEEL HUB)
SIR INDICATOR SHORTING BAR PNK REDUNDANT IND IGN 1 WIRE
TAN WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraint circuit -> MULTI- FUNCTION ALARM MODULE SAFETY BELT INPUT
