Buick Century V (1982-1996) luggage compartment light remote keyless entry module Wiring diagram

ANTENNA RELAY BATTERY BLK WIRE BLOWER RELAY BLU WIRE BRN WIRE BUICK RADIO MULTI- FUNCTION ALARM MODULE BUICK SEDAN CIRCUIT BREAKER COURTESY LIGHTS CTSY FUSE DAYTIME RUNNING LIGHTS MODULE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE MULTI- FUNCTION ALARM MODULE ELECTRONIC BRAKE CONTROL RELAY FRONT LIGHTS TAIL- LIGHTS FUEL PUMP IN-LINE FUSE FUEL PUMP/ OIL PRESSURE SENDER/SW FUEL PUMP RELAY FUSE BLOCK FUSIBLE LINK A (16 GA-RUST) FUSIBLE LINK B FUSIBLE LINK C FUSIBLE LINK D (20 GA-RUST) FUSIBLE LINK E FUSIBLE LINK F (16 GA-RUST) FUSIBLE LINK G (14 GA-RUST) GENERATOR GRY WIRE HEAD OFF PARK HEADLIGHT DIMMER SWITCH DAYTIME RUNNING LIGHTS (DRL) MODULE HEATER, A/C CONTROL ASSEMBLY HI LO I/P COMPARTMENT LIGHT HORN RELAY INST LPS LIGHT SWITCH LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPARTMENT LIGHT REMOTE KEYLESS ENTRY MODULE MASTER SWITCH ASSEMBLY LIGHT ASHTRAY LIGHT MULTI-FUNCTION ALARM IN-LINE FUSE NCA WIRE OLDS OLDS SEDAN OLDS, BUICK ORG/ WIRE POWERTRAIN CONTROL MODULE PRIMARY COOLANT FAN RELAY PUSHER COOLANT FAN RELAY RADIO RADIO INSTRUMENT CLUSTER REAR DEFOGGER CONTROL REAR DOME LIGHT FRONT DOME LIGHT INSIDE LIGHTED MIRROR ASSEMBLY RED WIRE RED/WHT WIRE REMOTE DIMMER MODULE REMOTE KEYLESS ENTRY MODULE RIGHT DOOR COURTESY LIGHT LEFT VANITY MIRROR LIGHT RIGHT VANITY MIRROR LIGHT RIGHT FRONT WINDOW SWITCH STARTER SOLENOID ASSEMBLY TAIL FUSE TO IGNITION SWITCH TO PWR/ACC CIRCUIT BREAKER (FUSE BLOCK) TO STOP-HAZ FUSE (FUSE BLOCK) UNDERHOOD LIGHT VIN M ONLY W/DRL WAGON YEL WIRE
