Buick Century V (1982-1996) left safety belt lap retractor release solenoid Wiring diagram
This page shows the only wiring diagram for the component.left safety belt lap retractor release solenoid, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left safety belt lap retractor release solenoid (1 of 1)
ANTI-LOCK BRAKE SYSTEM
BATTERY
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER
DK GRN WIRE
DRIVER'S DOOR LATCH
FASTEN BELTS INDICATOR CONTROL
FRONT DOOR OPEN INPUT
FUSE BLOCK
GAGES FUSE
GROUND
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
IGNITION
INSTRUMENT CLUSTER FASTEN BELTS INDICATOR
LEFT
LEFT SAFETY BELT LAP RETRACTOR RELEASE SOLENOID
LEFT SAFETY BELT SHOULDER RETRACTOR RELEASE SOLENOID
LT BLU WIRE
LT GRN/BLK WIRE
MULTI-FUNCTION ALARM IN-LINE FUSE
MULTI-FUNCTION ALARM MODULE
NCA WIRE
OLDS, BUICK
ORG/ WIRE
PASSENGER'S DOOR LATCH
PNK WIRE
POWERTRAIN CONTROL MODULE
RIGHT FRONT DOOR OPEN INPUT
RIGHT SAFETY BELT LAP RETRACTOR RELEASE SOLENOID
RIGHT SAFETY BELT SHOULDER RETRACTOR RELEASE SOLENOID
SAFETY BELT INPUT
SAFETY BELT SOLENOID CONTROL
SAFETY BELT SWITCH
SWITCH
VEHICLE SPEED INPUT
VEHICLE SPEED OUTPUT
YEL WIRE
Go to component -> Passive restraint circuit -> LEFT SAFETY BELT LAP RETRACTOR RELEASE SOLENOID
