Buick Century V (1982-1996) inst lps fuse 5 a Wiring diagram
This page shows the only wiring diagram for the component.inst lps fuse 5 a, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inst lps fuse 5 a (1 of 1)
BLK WIRE
FUSE BLOCK- I/P
GAGES FUSE 10 A
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
HOT WITH HEADLIGHTS ON
INST LPS FUSE 5 A
ON INDICATOR
ORG/ WIRE
PANEL LIGHT
PNK WIRE
PPL
PPL REAR DEFOGGER
PWR ACC CIRCUIT BREAKER 30 A
REAR DEFOGGER
REAR DEFOGGER CONTROL
REAR DEFOGGER SWITCH
SEDAN
TIMER
WAGON
Go to component -> Defogger circuit -> INST LPS FUSE 5 A
