Buick Century V (1982-1996) eng/ a/c fuse turn/ b/u fuse Wiring diagram
This page shows the only wiring diagram for the component.eng/ a/c fuse turn/ b/u fuse, which is found in the car Buick Century V (1982-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eng/ a/c fuse turn/ b/u fuse (1 of 1)
#3 #4
#5 #6
+2 -1
AIRBAG FUSE
ARMING SENSOR
AUTO DOOR UNLOCK MODULE
DAYTIME RUNNING LIGHTS MODULE
DIAGNOSTIC ENERGY RESERVE MODULE
ELECTRONIC IGNITION MODULE
ENG/ A/C FUSE TURN/ B/U FUSE
FIBER OPTIC LIGHT SOURCE DIAGNOSTIC ENERGY RESERVE MODULE CRUISE CONTROL MODULE
FROM IGNITION SWITCH
FUEL INJECTORS
FUSE BLOCK
GAGES FUSE
INJ/ COIL FUSE
INSTRUMENT CLUSTER
LAMP DRIVER MODULE
MASS AIRFLOW SENSOR POWERTRAIN CONTROL MODULE POWERTRAIN CONTROL MODULE
MULTI-FUNCTION LEVER
OLDS, BUICK
PARK/ NEUTRAL POSITION SWITCH
PCM FUSE
PNK PNK PNK BUICK (OLDS) (BUICK) WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK W/DRL WIRE
PNK WIRE
PNK/BLK WIRE
PRIMARY COOLANT FAN RELAY A/C COMPRESSOR CONTROL RELAY
PUSHER COOLANT FAN RELAY
TURN FLASHER CRANKSHAFT POSITION SENSOR
UNLOCK FUSE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> ENG/ A/C FUSE TURN/ B/U FUSE
