Buick Century V (1982-1996) backup lights circuit pnk Wiring diagrams

BACKUP LIGHTS CIRCUIT PNK WIRE BLK WIRE BLU WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) BRN WIRE CONVENIENCE CENTER (BEHIND LEFT SIDE OF I/P) DAYTIME RUNNING LIGHTS MODULE (BEHIND CENTER OF I/P) DK BLU WIRE DK DK FUSE FUSE BLOCK GRN WIRE HAZARD HAZARD FLASHER HEAD OFF PARK HIGH LEVEL STOP LIGHT HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START INSTRUMENT CLUSTER LEFT FRONT MARKER LIGHT LEFT FRONT PARK/TURN LIGHT LEFT REAR MARKER LIGHT LEFT REAR TAIL/ STOP/ TURN LIGHTS LEFT TAIL LIGHTS LEFT TURN IND. LT LEFT TURN SWITCH LICENSE LIGHT LIGHT SWITCH PARK LAMPS CTRL NCA WIRE NORMAL ORG/ WIRE PNK WIRE PPL PPL RADIO RIGHT FRONT MARKER LIGHT RIGHT REAR MARKER LIGHT RIGHT REAR TAIL/ STOP/ TURN LIGHTS RIGHT TAIL LIGHTS RIGHT TURN IND RIGHT TURN SWITCH STOP HAZ TAIL FUSE TURN B/U TURN FLASHER TURN/ HAZARD SWITCH ASSEMBLY W/DRL ONLY W/O LUGGAGE CARRIER WARNING SYSTEMS PPL WHT WIRE WITH LUGGAGE CARRIER YEL WIRE

392 OHM BACKUP LIGHTS CIRCUIT PNK WIRE BLK WIRE BLU WIRE BRN WIRE CONVENIENCE CENTER (RIGHT I/P, RIGHT OF I/P COMPT) DAYTIME RUNNING LIGHTS MODULE (BEHIND CENTER OF I/P) DK DK FUSE FUSE BLOCK (BEHIND RIGHT I/P) GRN WIRE HAZARD HAZARD FLASHER HEAD OFF PARK HIGH LEVEL STOP LIGHT HIGH LEVEL STOP LIGHT IN-LINE RESISTOR (IN LIFTGATE, NEAR PASS THRU) HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START INSTRUMENT CLUSTER LEFT FRONT MARKER LIGHT LEFT FRONT PARK/ TURN LIGHT LEFT REAR MARKER LIGHT LEFT REAR TAIL/ STOP/ TURN LIGHTS LEFT TURN IND. LT LEFT TURN SWITCH LICENSE LIGHT LIGHT SWITCH PARK LAMPS CTRL NCA WIRE NORMAL ORG/ WIRE PNK WIRE PPL PPL WARNING SYSTEMS RADIO RIGHT FRONT MARKER LIGHT RIGHT FRONT PARK/ TURN LIGHT RIGHT REAR MARKER LIGHT RIGHT REAR TAIL/ STOP/ TURN LIGHTS RIGHT TURN IND RIGHT TURN SWITCH STOP HAZ STOP LAMP BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) TAIL FUSE TURN B/U TURN FLASHER TURN/ HAZARD SWITCH ASSEMBLY UNDERHOOD LIGHT W/DRL ONLY WHT WIRE YEL WIRE
