Courtesy lamps circuit for BMW Z4 G29 facelift (2022-2024)

BLU/YEL WIRE BODY DOMAIN CONTROLLER BOTTOM CENTER DASHBOARD LIGHTING BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR GROUND LIGHTS FRONT PASSENGER'S DOOR GROUND LIGHTS FRONT PASSENGER'S DOOR INSIDE DOOR HANDLE LIGHT FUSE 504 FUSE 61 FUSE 62 FUSE 66 FUSE 67 FUSE 68 FUSE BOX GLOVE BOX LIGHT SWITCH GLOVE COMPARTMENT LIGHT GRN WIRE GRY WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ LIGHT SOURCE 1 LIGHT SOURCE 2 LIGHT SOURCE 3 RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT FRONT POWER DISTRIBUTION BOX TOP FRONT PASSENGER'S DOOR TRIM PANEL LIGHTING VIO/GRN WIRE WHT WIRE WHT/VIO WIRE YEL WIRE

BLU/YEL WIRE BOTTOM DRIVER'S SIDE DASHBOARD LIGHTING BRN WIRE BRN/BLK WIRE CENTER CONSOLE LIGHTING CENTER STACK STORAGE COMPARTMENT LIGHTING DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT FRONT CENTER ARMREST LIGHT GRY/BLK WIRE LEFT FRONT FOOTWELL LIGHT LEFT FRONT VANITY MIRROR LIGHT LEFT FRONT VANITY MIRROR SWITCH LIGHT SOURCE 10 LIGHT SOURCE 4 LIGHT SOURCE 5 LIGHT SOURCE 6 LIGHT SOURCE 7 LIGHT SOURCE 9 RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT VANITY MIRROR LIGHT RIGHT FRONT VANITY MIRROR SWITCH VIO/GRN WIRE W/ INTERIOR LIGHT PACKAGE WHT WIRE WHT/GRY WIRE WHT/VIO WIRE YEL WIRE

BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR ENTRY LIGHTING FRONT INTERIOR LIGHT FRONT PASSENGER'S DOOR ENTRY LIGHTING FUSE 254 INTERFERENCE SUPPRESSION FILTER 2 LEFT FRONT FOOTWELL LIGHT LIGHT SOURCE 8 LUGGAGE COMPARTMENT LAMP REAR POWER DISTRIBUTION BOX RED/BRN WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT FOOTWELL LIGHT TAILGATE LOCK TOP DRIVER'S DOOR TRIM PANEL LIGHTING VIO/GRN WIRE W/O INTERIOR LIGHT PACKAGE WHT WIRE WHT/VIO WIRE YEL WIRE
