BMW Z4 G29 (2018-2022) bottom driver side dashboard lighting Wiring diagram
This page shows the only wiring diagram for the component.bottom driver side dashboard lighting, which is found in the car BMW Z4 G29 (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bottom driver side dashboard lighting (1 of 1)
BLU/YEL WIRE
BOTTOM DRIVER SIDE DASHBOARD LIGHTING
BRN WIRE
BRN/BLK WIRE
CENTER CONSOLE LIGHTING
CENTER STACK STORAGE COMPARTMENT LIGHTING
DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT
FRONT CENTER ARMREST LIGHT
GRY/BLK WIRE
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT VANITY MIRROR LIGHT
LEFT FRONT VANITY MIRROR SWITCH
LIGHT SOURCE 10
LIGHT SOURCE 4
LIGHT SOURCE 5
LIGHT SOURCE 6
LIGHT SOURCE 7
LIGHT SOURCE 9
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
VIO/GRN WIRE
W/ INTERIOR LIGHT PACKAGE
WHT WIRE
WHT/GRY WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> BOTTOM DRIVER SIDE DASHBOARD LIGHTING
