Trunk & fuel door release circuit for BMW Z4 E89 facelift (2013-2017)
Trunk & fuel door release circuit
BLK/BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLK WIRE
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUNCTION BOX
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 72
FUSE 73
GRN WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOTEL SWITCH
JUNCTION BOX
LEFT REAR LID LOCK SWITCH
ORG/GRN WIRE
REAR LID RELEASE SWITCH (INTERIOR)
RIGHT REAR LID LOCK SWITCH
TRUNK LID BUTTON
TRUNK LID CENTRAL LOCKING DRIVE
WHT/BRN WIRE
WHT/GRN WIRE
YEL/BLU WIRE
