Headlamps circuit for BMW Z4 E89 facelift (2013-2017)

BI-XENON SHUTTER ACTIVATION BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BRK/REAR FOG LIGHT BRN WIRE BRN/BLK WIRE BRN/YEL WIRE BULB XENON HEADLIGHT COMPUTER DATA LINES SYSTEM FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FRONT LVL SNSR SIG FUSE 41 FUSE 81 FUSE 84 FUSE 86 GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HAZARD SW SIG HEADLAMP RANGE CONTROL POSITION MOTOR HEADLIGHT BEAM CTRL SIG HEADLIGHT BEAM HEIGHT SIG HIGH BEAM/ HEADLIGHT SW SIG HOT AT ALL TIMES JUNCTION BOX K-BUS SIG LEFT HEADLIGHT LEFT TAILLIGHT LOW BEAM SIG LOW BEAM SW SIG LT SW SIG LVL SNSR SPLY MODULE ORG/GRN WIRE PARKING LT SIG RAIN/HEADLIGHT SENSOR REAR FOG REAR FOG LT SIG REAR LVL SNSR SPLY RED WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIDE SNSR GND ROOF FUNCTION CONTROL CENTER SIDE MARKER LT SIG SIDE/ DAYTIME DRIVING LIGHT TERM 30 WHT WIRE WHT/BRN WIRE XENON LAMPS YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE BULB XENON HEADLIGHT COMPUTER DATA LINES SYSTEM DIRECTION INDICATOR/ HIGH BEAM HEADLIGHT SWITCH FRONT RIDE HEIGHT SENSOR GRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLAMP RANGE CONTROL POSITION MOTOR HOT AT ALL TIMES JUNCTION BOX LIGHT SWITCH UNIT MODULE PARKING BRAKE CONTROL MODULE PARKING BRAKE PUSH BUTTON REAR FOG REAR RIDE HEIGHT SENSOR RED WIRE RIGHT HEADLIGHT RIGHT TAILLIGHT SIDE/ DAYTIME DRIVING LIGHT STEERING COLUMN SWITCH CLUSTER WHT WIRE XENON LAMPS YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE
