BMW Z4 E89 facelift (2013-2017) steering column switch cluster direction indicator/ high beam headlight switch Wiring diagram
This page shows the only wiring diagram for the component.steering column switch cluster direction indicator/ high beam headlight switch, which is found in the car BMW Z4 E89 facelift (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column switch cluster direction indicator/ high beam headlight switch (1 of 1)
3.0L TWIN TURBO 2.0L TURBO
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRAKE/
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
CAR ACCESS SYSTEM
DAY TIME
DIRECTION
DME CONTROL MODULE
DYNAMIC STABILITY CONTROL (DSC)
FOG
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/VIO WIRE
LEFT HEADLIGHT
LEFT TAILLIGHT
LIGHT SWITCH UNIT
PARK
REVERSE
RIGHT TAILLIGHT
SIDE MARKER
SIDE/DRIVING
STEERING COLUMN SWITCH CLUSTER DIRECTION INDICATOR/ HIGH BEAM HEADLIGHT SWITCH
TURN
VIO/WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> STEERING COLUMN SWITCH CLUSTER DIRECTION INDICATOR/ HIGH BEAM HEADLIGHT SWITCH
