BMW Z4 E89 facelift (2013-2017) left rear oddments compartment lighting Wiring diagram
This page shows the only wiring diagram for the component.left rear oddments compartment lighting, which is found in the car BMW Z4 E89 facelift (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear oddments compartment lighting (1 of 1)
3.0L TWIN TURBO
ACTIVE SOUND DESIGN
AMPLIFIER
ANTENNA DIVERSITY
AUC SENSOR
AUXILIARY BRAKE LIGHT
BASE PLATE
BLU/GRN WIRE
BRN WIRE
BRN/BLK WIRE
CAR INFORMATION COMPUTER CIC
CD CHANGER
COMBOX
COMFORT ACCESS CONTROL MODULE
CONTROLLER
CONVERTIBLE TOP MODULE
DIGITAL TUNER
DIODE PANEL
DVD CHANGER
EJECT BOX
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
ELECTRONIC POWER STEERING (EPS)
FOOTWELL MODULE
FUEL PUMP CONTROL (EKPS)
GEAR INDICATOR LIGHTING
GEAR SELECTOR SWITCH
HARDTOP DRIVE UNIT RELAY 1
HARDTOP DRIVE UNIT RELAY 2
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION COILS INTERFERENCE SUPPRESSION CAPACITOR
LEFT AUTOMATIC SOFT CLOSE DRIVE
LEFT LICENSE PLATE LIGHT
LEFT REAR LID LOCK SWITCH
LEFT REAR ODDMENTS COMPARTMENT LIGHTING
LEFT TAIL LIGHT
NCA WIRE
PARK DISTANCE CONTROL (PDC)
PARKING BRAKE CONTROL MODULE
PARKING BRAKE PUSH BUTTON
RADIO
REAR WINDOW DEFOGGER
RIGHT AUTOMATIC SOFT CLOSE DRIVE
RIGHT LICENSE PLATE LIGHT
RIGHT REAR ODDMENTS COMPARTMENT LIGHTING
RIGHT TAIL LIGHT
SATELLITE RECEIVER
STEPTRONIC SWITCH
TCU
TELEPHONE RETROFIT PACKAGES CONNECTOR
TELEPHONE TRANSCEIVER
TIRE PRESSURE CONTROL (RDC)
TOP ODDMENTS COMPARTMENT LIGHTING
TOP OF ENGINE)
TRUNK LID BUTTON
TRUNK LID CENTRAL LOCKING DRIVE
ULF-SBX
USB- HUB
VIDEO MODULE
W/ CD CHANGER
W/ CIC
W/ DVD CHANGER
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (3 of 3) -> LEFT REAR ODDMENTS COMPARTMENT LIGHTING
