BMW Z4 E89 facelift (2013-2017) left rear module closed micro switch Wiring diagram
This page shows the only wiring diagram for the component.left rear module closed micro switch, which is found in the car BMW Z4 E89 facelift (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear module closed micro switch (1 of 1)
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE
GRN WIRE
GRY WIRE
GRY/BRN WIRE
HARDTOP DRIVE UNIT
HARDTOP DRIVE UNIT RELAY 1
HYDRAULIC OIL TEMPERATURE SENSOR
LEFT REAR MODULE CLOSED MICRO SWITCH
LEFT ROOF PANEL 2 CLOSED MICRO SWITCH
NCA WIRE
NEGATIVE SPLY
ORG/ WIRE
POSITIVE ACT
POSITIVE SPLY
REAR MODULE OPEN HALL SENSOR
RED WIRE
RED/YEL WIRE
RETRACTABLE HARDTOP VALVE 1
RETRACTABLE HARDTOP VALVE 2
RETRACTABLE HARDTOP VALVE 3
RIGHT REAR MODULE CLOSED MICRO SWITCH
RIGHT ROOF PANEL 2 CLOSED MICRO SWITCH
ROOF PACKAGE DOWN MICRO SWITCH
ROOF PACKAGE UP HALL SENSOR
ROOF PANEL 2 PACKED HALL SENSOR
ROOF SEGMENT
ROOF SEGMENTS VALVE
SENS GND
SHIGLD
SIG
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WINDSCREEN COWL PANEL LOCKED MICRO SWITCH
WINDSCREEN COWL PANEL RELEASED MICRO SWITCH
YEL WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> LEFT REAR MODULE CLOSED MICRO SWITCH
