Heated seats circuit, with memory for BMW Z4 E89 (2009-2013)
Heated seats circuit, with memory
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
CENTER CONSOLE SWITCH CENTER
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING ELEMENT
DRIVER'S SEAT CUSHION HEATING ELEMENT
DRIVER'S SEAT MODULE (UNDER DRIVER'S SEAT)
ELECTRONICS JUNCTION BOX
FUSE 46
GRN WIRE
GRY WIRE
HEATING/ AIR CONDITIONING SYSTEM
JUNCTION BOX (RIGHT SIDE OF DASH)
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RELAY ENERGIZED FUSE 77
VIO WIRE
VIO/GRY WIRE
WHT WIRE
YEL/BRN WIRE
YEL/GRN WIRE
