BMW Z4 E89 (2009-2013) windscreen cowl panel locked micro switch windscreen Wiring diagram
This page shows the only wiring diagram for the component.windscreen cowl panel locked micro switch windscreen, which is found in the car BMW Z4 E89 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windscreen cowl panel locked micro switch windscreen (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 SHIGLD
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CONVERTIBLE TOP MODULE (RIGHT REAR OF LUGGAGE COMPT)
GRN WIRE
GRY WIRE
GRY/BRN WIRE
HARDTOP DRIVE UNIT
HARDTOP DRIVE UNIT RELAY 1
HYDRAULIC OIL TEMPERATURE SENSOR
LEFT REAR REAR MODULE MODULE CLOSED OPEN MICRO SWITCH HALL SENSOR
LEFT ROOF PANEL 2 CLOSED MICRO SWITCH
NCA WIRE
ORG/ WIRE
POSITIVE SPLY POSITIVE SPLY POSITIVE ACT POSITIVE ACT POSITIVE ACT
RED WIRE
RED/YEL WIRE
RETRACTABLE HARDTOP VALVE 1
RETRACTABLE HARDTOP VALVE 2
RETRACTABLE HARDTOP VALVE 3
RIGHT REAR MODULE CLOSED MICRO SWITCH
RIGHT ROOF PANEL 2 CLOSED MICRO SWITCH
ROOF PACKAGE DOWN MICRO SWITCH
ROOF PACKAGE UP HALL SENSOR
ROOF PANEL 2 PACKED HALL SENSOR
SENS GND
SIG SIG SIG SIG SIG SIG SIG SIG SIG SIG
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WINDSCREEN COWL PANEL LOCKED MICRO SWITCH WINDSCREEN
WINDSCREEN COWL PANEL RELEASED MICRO SWITCH
YEL WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> WINDSCREEN COWL PANEL LOCKED MICRO SWITCH WINDSCREEN
