BMW Z4 E89 (2009-2013) right rear oddments compa- rtment light left rear oddments compa- rtment light Wiring diagram
This page shows the only wiring diagram for the component.right rear oddments compa- rtment light left rear oddments compa- rtment light, which is found in the car BMW Z4 E89 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear oddments compa- rtment light left rear oddments compa- rtment light (1 of 1)
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR ENTRANCE LIGHT TOP ODDMENTS COMPA- RTMENT LIGHTING
DRIVER'S SIDE FOOTWELL LIGHT
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE (UNDER LEFT SIDE OF DASH)
FRONT INTERIOR LIGHT
FRONT INTERIOR/ READING LAMP
FUSE 41
FUSE 62
FUSE 7
FUSE 77
FUSE 81
FUSE 84
GLOVE COMPARTMENT LIGHT
GRN WIRE
GRN/WHT WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
INSTRUMENT ILLUMINATION CIRCUIT
JUNCTION BOX (RIGHT SIDE OF DASH)
LEFT REAR LID LOCK SWITCH
NCA WIRE
ORG/GRN WIRE
PASSENGER'S DOOR COURTESY LIGHT
PASSENGER'S DOOR ENTRANCE LIGHT
PASSENGER'S SIDE FOOTWELL LIGHT
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT LUGGAGE COMPARTMENT LIGHT
RIGHT REAR ODDMENTS COMPA- RTMENT LIGHT LEFT REAR ODDMENTS COMPA- RTMENT LIGHT
ROOF FUNCTION CONTROL CENTER (W/ LIGHT PACKAGE)
VIO/BRN WIRE
W/ LIGHT PACKAGE W/O LIGHT PACKAGE
WHT/BRN WIRE
Go to component -> Instrument illumination circuit -> RIGHT REAR ODDMENTS COMPA- RTMENT LIGHT LEFT REAR ODDMENTS COMPA- RTMENT LIGHT
