BMW Z4 E89 (2009-2013) passenger's lumbar support valve block Wiring diagrams
This page contains all the electrical diagrams for the component. passenger's lumbar support valve block, in which he is found in the car BMW Z4 E89 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
passenger's lumbar support valve block wiring diagram (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRN WIRE
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT VACUUM PUMP
FUSE 20 BOX (RIGHT SIDE OF DASH)
GRY WIRE
GRY/BLK WIRE
JUNCTION
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
PASSENGER'S SEAT VACUUM PUMP
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
SPORT SEAT CIRCUIT
VIO WIRE
Go to component -> Lumbar circuit -> PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
passenger's lumbar support valve block wiring diagram (2 of 2)
A/T
BISTABLE RELAY
BLK WIRE
BLU WIRE
COMBOX
COMFORT DRIVER'S ACCESS SIDE OUTER CONTROL DOOR HANDLE MODULE ELECTRONIC MODULE
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
EDC ELECTRONIC DAMPER CONTROL
EJECT BOX
ELECTRONICS JUNCTION BOX
FROM FUSE 70 (DIAGRAM 3 OF 4)
FROM FUSE 73 (DIAGRAM 2 OF 4)
FROM JUNCTION BOX (DIAGRAM 2 OF 4)
FUSE 20
FUSE 22
FUSE 23
FUSE 61
FUSE 74
GRN WIRE
INSTRUMENT CLUSTER CONTROL MODULE
JUNCTION BOX (RIGHT SIDE OF DASH)
NCA WIRE
OBDII SOCKET
PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
TCU
TO TERMINAL 15 RELAY (DIAGRAM 3 OF 4)
TRANSMISSION CONTROL
TRANSMISSION CONTROL DKG
W/ COMBOX
W/ DOUBLE CLUTCH A/T
W/ O COMBOX
W/ O COMBOX FUSE 59
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> PASSENGER'S LUMBAR SUPPORT VALVE BLOCK
