Trunk & fuel door release circuit for BMW Z4 E85/E86 facelift (2005-2009)
Trunk & fuel door release circuit
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CENTRAL LOCKING DRIVE, STORAGE COMPARTMENT (TOP REAR OF CENTER CONSOLE)
CENTRAL LOCKING DRIVE, TRUNK LID (REAR COMPARTMENT DOOR)
CENTRAL LOCKING FUEL FILTER FLAP (FRONT OF RIGHT REAR WHEEL)
COUPE
EXCEPT COUPE
FUSE
GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH)
GRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN OR START
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
REAR LID RELEASE SWITCH (INTERIOR)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
TRUNK LID/TAILGATE LOCK SWITCH
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
