Premium radio circuit, top hifi radio for BMW Z4 E85/E86 facelift (2005-2009)

ANTENNA ANTENNA DIVERSITY (LEFT SIDE OF REAR COMPT) AV SOCKET AV SOCKET NAVI + BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE CD AF+ L CD AF+ R CD AF- CD CHANGER COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM (LEFT FRONT LUGGAGE COMPT) FM AMPLIFIER FM ANTENNA FUSE GROUND ANTENNA LIGHT TERM 30 TERM R GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, ACC OR START K-BUS MUTE LEFT TV ANTENNA NAVIGATION SYSTEM (REAR CENTER CONSOLE) NCA WIRE POWER DISTRIBUTION (RIGHT SIDE OF DASH) R - L - RADIO RADIO NAVI AV SOCKET SH NAVI - RED/BLU WIRE RED/YEL WIRE RIGHT TV ANTENNA TELEPHONE TRANSCEIVER VIDEO MODULE (REAR CENTER OF REAR COMPT) VIO/WHT WIRE VOICE CONTROL SYSTEM W/ ANTENNA DIVERSITY W/ VIDEO MODULE W/O ANTENNA DIVERSITY W/O VIDEO MODULE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

AMPLIFIER (REAR LUGGAGE COMPARTMENT) ANT AV SOCKET BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE BOX (REAR LUGGAGE COMPT) HOT AT ALL TIMES LEFT CARVER SUBWOOFER LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER SPEAKER LEFT FRONT WOOFER SPEAKER LEFT REAR MID-RANGE SPEAKER MUTE TELE AF+ LF A- LR MR+ LR MR- LFT+ LFT- NCA WIRE R AF+ ANT RFT+ RFT- RR MR+ R AF- K-BUS RED WIRE RED/BRN WIRE RED/YEL WIRE RIGHT CARVER SUBWOOFER RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER SPEAKER RIGHT FRONT WOOFER SPEAKER RIGHT REAR MID-RANGE SPEAKER ROD ANTENNA RR MR- RFW- RFW+ R SUB- R SUB+ 31 TERM 50 LF A+ LF MR- LF MR+ RF MR- RF MR+ W/ ANTENNA DIVERSITY W/O ANTENNA DIVERSITY WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
